TREE SHEAR
“BIG INCH” – BI500
BI500 is the real game changer for big projects. Developed for excavators from 23 t to 40 t, with 110 t cylinder of force, BI500 is able to carry a 600 mm cutting diameter.
DOWNLOAD BROCHURE
Excavator class weight
23 – 40 tons
Attachment weight
1810 Kg / 3990 Lbs
Min. cut diameter
8" / 200 mm
Max. cut diameter
500 / 600 mm - 20" / 24"
Oil pressure
300 – 350 bar | 4350-5075 psi (min-max)
Hydraulic flow
125 – 180 l/min | 48-80 gal/min (min-max)
Width
65" / 1665 mm
Length
77" / 1940 mm
Height
35" / 890 mm
